CHROMEWELD™ 600
CHROMEWELDTM 600 is a premium grade overlay plate manufactured using a proprietory chemistry under a tightly controlled manufacturing process, that produces a microstructure of a fully austenitic matrix filled with primary carbides designed to withstand extreme abrasion wear with continuous moderate impact.
GENERAL OVERLAY CHEMISTRY
• Hardness ranges from 58-62 HRC, based on weld deposit thickness.
• Remains abrasion resistant at temperature’s up to 600°C.
• Backing Plate can be customised as per the user requirement to Stainless Steel, Other Carbon Steels.
• CHROMEWELDTm 600 is highly formable due to its Manufacturing Process.
• CHROMEWELDTm 600 exhibits a Consistent Deposition of High Density Carbides across the overlay thickness exhibiting High Performance.
• Available Thicknesses range from 6mm ( 3mm + 3mm ) to 37mm ( 12mm + 25mm ).
OUR USP
Proprietary Chemistry
Highly Formable
Unique Manufacturing Process
Consistent Microstructure
100% Traceability
Minimal Dilution
| Typical Chemistry (%) | |||||
|---|---|---|---|---|---|
| C 4.5-6 |
Cr 25-30 |
Mn 0-2 |
Si 0-2 |
Si 0.55 Max |
Fe Balance |
Casted Overlay
Jadco fusion Overlay
